Daffodil Heat Shrinkable Cable Terminations 24 kV for XLPE/EPR Insulating Cable are suitable for XLPE or EPR insulation up to 24 kV.
| CABLE SIZE (Sq. mm) | FOR 22 kV INDOOR (Kit Code) |
|---|---|
| 3 x 16 - 50 | DXE - 21 |
| 3 x 70 - 120 | DXE - 22 |
| 3 x 150 - 185 | DXE - 23 |
| 3 x 240 - 400 | DXE - 24 |
| CABLE SIZE (Sq. mm) | FOR 22 kV OUTDOOR (Kit Code) |
| 3 x 16 - 35 | DXO - 21 |
| 3 x 70 - 120 | DXO - 22 |
| 3 x 150 - 185 | DXO - 23 |
| 3 x 240 - 400 | DXO - 24 |
| Test Sequence | 6.35/11 kV |
|---|---|
| D.C. Voltage with stand / 15 min | 96 kV |
| Impulse Voltage with stand | 125 kV |
| Impulse Voltage with stand | 50 kV |
| Discharge Extinction Voltage(<5pc) | More than 25kV |
