Heat Shrinkable Straight Joint upto 36kV (For Aerial Bunched Cable)

Daffodil Heat Shrinkable Straight Joint upto 36 kV (For Aerial Bunched Cable) are suitable for Cable joining Kit fixed or flexible cables insulation up to 36kV.

  • Minimises jointer’s skills.
  • The Products are carefully selected compositions of raw materials to meet the most stringent demands.
  • We also offer tailor-made solutions against specific requirements.
  • Continuous operation temperature: -55°C to 120°C.
  • Corrosion resistant and unlimited shelf life.
  • High resistance to impact and abrasion.
  • In compliance with various international specifications and standards (IEC-60502-4 / IS:13573).
  • Electrolytic grade connectors.
ORDERING REFERENCE
CABLE SIZE (Sq. mm) FOR 11 kV Straight Through Joint (For AB Cable) (Kit Code)
1 x 16 - 50 DXSS/AB - 11
1 x 70 - 120 DXSS/AB - 12
1 x 150 – 300 DXSS/AB - 13
1 x 400 - 630 DXSS/AB - 14
1 x 800 - 1000 DXSS/AB - 15
CABLE SIZE (Sq. mm) FOR 22 KV Straight Through Joint (For AB Cable) (Kit Code)
1 x 25 - 50 DXSS/AB - 21
1 x 70 - 150 DXSS/AB - 22
1 x 185 - 300 DXSS/AB - 23
1 x 400 - 630 DXSS/AB - 24
1 x 800 - 1000 DXSS/AB - 25
CABLE SIZE (Sq. mm) FOR 33 kV Straight Through Joint (For AB Cable) (Kit Code)
1 x 25 – 50 DXSS/AB - 31
1 x 70 - 185 DXSS/AB - 32
1 x 240 - 500 DXSS/AB - 33
1 x 630-800 DXSS/AB - 34
1 x 1000 DXSS/AB - 35
Technical Specifications
Test Sequence 6.35/11 kV 12.7/22 kV 19/33 kV
D.C. Voltage with stand / 15 min 48 kV 96 kV 144 kV
Impulse Voltage with stand 75 kV 125 kV 170 kV
Impulse Voltage with stand 35 kV 50 kV 75 kV
Discharge Extinction Voltage(<5pc)< /td> More than 13kV More than 25.4kV More than 38kV
